Nruas coil inductors yog li lub npe hu ua tus neeg xyuas pib (ib puag ncig hlau nplaum hlau) yog qhov txhab ncaj qha mus rau ferrite core uas yog zoo li lub nruas lossis spool. Tom qab ntawd cov hlau txuas nrog rau lub hauv paus, ib lub hauv paus yas los yog hlau lead thav duab los tsim qhov mount qhov xaus. Nruas Coil Inductor yog ib qho me me choke coil fais fab inductor. Lub hwj chim inductor, tseem hu ua choke coil, choke lossis txawv hom inductors, yog siv los txwv qhov hloov pauv tam sim no los ntawm lub kauj. Nws muaj qhov zoo Q siab, siab tus kheej resonance zaus, thiab me me sib nqus flux to. Tsis tas li ntawd, lub zog inductor muaj kev tiv thaiv zoo sib nqus thiab tsis muaj RoHS.
Lub luag haujlwm tseem ceeb ntawm Drum coil inductors yog filtering, boost, puck, Circuit Court cais, thiab lwm yam. Nyob rau hauv cov nqe lus ntawm lub hwj chim filtering, plug-in inductor feem ntau yog siv nyob rau hauv cov zis ntawm DC fais fab mov, los ntawm lub inductance ntawm inductor thiab lub inductor. capacitance ntawm lub capacitor los lim tawm cov suab nrov nrov hauv cov khoom siv fais fab, kom ntseeg tau tias cov zis tam sim no ruaj khov thiab ntshiab. Nyob rau hauv cov nqe lus ntawm voltage boost, lub plug-in inductor tuaj yeem ua tiav cov txiaj ntsig ntawm qhov hluav taws xob nce los ntawm qhov siab permeability ntawm cov tub ntxhais thiab cov lej ntawm cov kauj. Nyob rau hauv cov nqe lus ntawm kev txo voltage, lub plug-in inductor tuaj yeem ua tiav cov txiaj ntsig ntawm kev txo qis los ntawm qhov qis permeability ntawm cov tub ntxhais thiab cov lej ntawm cov kauj. Nyob rau hauv cov nqe lus ntawm kev rho tawm Circuit Court, plug-in inductors feem ntau yog siv los cais cov kev cuam tshuam ntau zaus hauv Circuit Court thiab tiv thaiv kev sib nrig sib cuam tshuam ntawm cov circuits.
| Series | Qhov Loj (mm) | ||||
| Ib Max. | B Max. | C Ref. | D | E Ref. | |
| DR 0406 | 5.50 | 8.00 | 15.00 | 2.00±0.50 | 0.50 |
| DR 0608 | 7.50 | 10.00 | 15.00 | 3.00±0.50 | 0.60 |
| DR 0810 | 10.00 | 13.00 | 15.00 | 5.00±0.50 | 0.65 |
| DR 0912 | 11.00 | 15.00 | 15.00 | 5.00±0.50 | 0.80 |
| DR 1012 | 12.00 | 15.00 | 15.00 | 5.00±0.50 | 0.80 |
- Tus nqi qis.
- Ntau yam ntawm inductance.
- Qhov chaw me me mounting xav tau.
- Lwm hom uas tsis tshua muaj DCR, tam sim no loj, zoo tshaj plaws rau cov khoom siv hluav taws xob.
Daim ntawv thov:
- Cov khoom siv hluav taws xob, DC-DC converters, TVs, VTRs, Computer, Computer Peripherals, Cov Khoom Siv Hluav Taws Xob Hauv Tsev, ect.
Cim npe nrov: Tuam Tshoj nruas coil inductor manufacturers, lwm tus neeg, Hoobkas
