Lan Magnetics

LAN transformer yog teem nruab nrab ntawm lub transceiver thiab lub network cable los ua lub luag hauj lwm ntawm cov teeb liab coupling, high voltage cais, impedance txuam, waveform kho, EMI suppression thiab hais txog.

Xa kev nug

Ces

Tsham tam sim no

Hauj lwm lawm

Network-Isolation-Transformer-Hr60165

LAN magnetics tseem hu ua network rho tawm transformer lossis cov ntaub ntawv twj tso kua mis. Ib txwm LAN magnetics feem ntau yog ua ke ntawm yam tsawg kawg yog ob ntu: pulse transformer thiab hom hom choke. Qhov sib xyaw ua ke no xa ib qho 1: 1 tig piv rau ob qho tib si kis thiab tau txais txoj hauv kev. Lan magnetics feem ntau muaj toroidal zoo core (T-Core). Qhov kom zoo dua ntawm T-core yog vim nws qhov sib npaug kaw-kho cov tub ntxhais, qhov nyiaj ntawm cov hlau nplaum uas tawm sab nraud ntawm cov tub ntxhais, hu ua cov dej ntws tawm, tsawg. Yog li, T-core yog qhov ua tau zoo dua thiab muab qhov zoo ntawm kev cuam tshuam hluav taws xob tsawg (EMI).

Lan Transformer-7

Cov khoom no yog siv hauv RJ45 network interface card, Ethernet hloov, router, ADSL, VDSL cov khoom siv, EOC davhlau ya nyob twg, EPON / GPON tri-networks integration khoom, network set-top box, ntse TV, network koob yees duab, SDH / ATMSDH / ATM, PC motherboard, muaj motherboard thiab ob peb qhov chaw ntxiv.

Nta:

IEEE 802.3, ANSI X3.263
SMT & Thru Hole muaj
Qhov loj me

Daim ntawv thov:

10/100 Base - T Ib Ntu

Lan Transformer-9

Lan Transformer-10

Tshooj Naj Npawb	Tus nqi sib piv ± 2%		Insertion Loss 1-100MHz (dB Max)	Hla Tham 0 1-100MHz (dB Min)	CMR 0 1-100MHz (dB Min)	Rov qab poob (dB Max)			SCH	Pob
Tshooj Naj Npawb	Tx	Rx	Insertion Loss 1-100MHz (dB Max)	Hla Tham 0 1-100MHz (dB Min)	CMR 0 1-100MHz (dB Min)	30 MHz	50 MHz	80 MHz	SCH	Pob
LAN -101	1 CT: 1 TSI	1 CT: 1 TSI	1.1	35	30	18	15	13	1	A
LAN -102	1 CT: 1 TSI	1 CT: 1 TSI	1.1	35	30	18	15	13	2	A
LAN -103	2 CT: 1 ib	1 CT: 1 TSI	1.1	35	30	18	13	13	1	A
LAN -104	1.41 TSI: 1CT	1 CT: 1 TSI	1.1	35	30	18	13	13	1	A
LAN -121	1 CT: 1 TSI	1 CT: 1 TSI	1.2	38	42	18	13	12	3	B
LAN -122	1 CT: 1 TSI	1 CT: 1 TSI	1.2	38	38	16	13	12	4	B
LAN -123	2 CT: 1 ib	1 CT: 1 TSI	1.2	38	35	16	13	12	4	B
LAN -124	1 TSI: 1.41CT	1 CT: 1 TSI	1.2	38	42	16	13	12	3	B
LAN -125	1 TSI: 1.41CT	1 CT: 1 TSI	1.2	38	38	16	13	12	4	B
...										...
